Combined Acting

Valve Function Combined Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 3/4" BSP Direction 2/2 Way Body Material Brass Sealing Material FKM+PA (fluorelastomer+poliamiyde) Flow 40.0 L/min Pressure Rating 0-14 bar (0-203 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Combined Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 3/4" BSP Direction 2/2 Way Body Material Brass Sealing Material NBR+PA (Nitrile Rubber + Polyamide) Flow 40.0 L/min Pressure Rating 0-14 bar (0-203 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Combined Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 3/4" NPT Direction 2/2 Way Body Material Brass Sealing Material FKM+ PA (Fluoroelastomer + Polyamide) Flow 40.0 L/min Pressure Rating 0-10 bar (0-145 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Combined Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 3/4" BSP Direction 2/2 Way Body Material Brass Sealing Material NBR+PA (Nitrile Rubber + Polyamide) Flow 40.0 L/min Pressure Rating 0-10 bar (0-145 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Combined Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 1/2" BSP Direction 2/2 Way Body Material Brass Sealing Material FKM+ PA (Fluoroelastomer + Polyamide) Flow 40.0 L/min Pressure Rating 0-10 bar (0-145 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Combined Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 1/2" BSP Direction 2/2 Way Body Material Brass Sealing Material NBR+PA (Nitrile Rubber + Polyamide) Flow 40.0 L/min Pressure Rating 0-10 bar (0-145 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Combined Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 3/8" BSP Direction 2/2 Way Body Material Brass Sealing Material FKM+ PA (Fluoroelastomer + Polyamide) Flow 20.0 L/min Pressure Rating 0-10 Bar (0-145 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Combined Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 3/8" BSP Direction 2/2 Way Body Material Brass Sealing Material NBR+PA (Nitrile Rubber + Polyamide) Flow 20.0 L/min Pressure Rating 0-10 Bar (0-145 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Combined Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/2" NPT Direction 2/2 Way Body Material Stainless Steel - SS316 Sealing Material PTFE (polytetrafluorethylene) Flow 50.0 L/min Pressure Rating 0-14 bar (0-203 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOWNLOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Combined Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1" BSP Direction 2/2 Way Body Material Brass Sealing Material NBR+PA (Nitrile Rubber + Polyamide) Flow 90.0 L/min Pressure Rating 0-12 bar (0-174 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Our Auto Drain Kit is designed for direct and indirect-acting solenoid valves manufactured by ODE and available in sizes between 1/8" and 3". This comprehensive kit includes an adjustable flow connector and drain valve for efficient drainage of the valve and system. Pre-assembled and tested, the kit is easy to install and ensures optimal drainage of your solenoid valve. Retrofit your solenoid valves made from ODE with this Auto Drain Kit that provides an easy and convenient solution to draining excess moisture and condensate from your air compressor systems to ensure optimal performance and longevity. Commonly paired with Series 21LN, 21XN, 21IN, 21A, 21WN, 21AP All valves must use 8W, 12W or 14W coils [ ODE Series B, U or G] Contents: 1x 67" Power Plug 1x Digital Timer [P992276] OR Analog Timer [P992087] Download Data Sheets : Digital Timer | Analog Timer
