3/2 Way Valves

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Subplate Direction 3/2 Way Body Material Brass Sealing Material Ruby Flow 0.07 m 3 /h (0.081 gpm) Pressure Rating 0-12 bar (0 - 174 psi) Datasheet DOWNLOAD Certifications CE

Valve Function Direct Acting Valve Type General Purpose Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" NPT Direction 3/2 Way Body Material Forged Brass Sealing Material NBR Flow Coefficient (Cv) 0.1 gpm Pressure Rating 0-10 bar (0 - 145 psi) Vacuum Rating 0.001 Torr Certifications CSA, UL, CE Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe Subplate Direction 3/2 Way Body Material Brass Sealing Material FKM (fluoroelastomer) Flow 1.4 L/min Pressure Rating 0-16 bar (0-232 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe Subplate Direction 3/2 Way Body Material Brass Sealing Material FKM (fluoroelastomer) Flow 1.4 L/min Pressure Rating 0-16 bar (0-232 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Total Separation Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Pipe 1/8" BSP Direction 3/2 Way Body Material PSU Sealing Material VMQ (Silicon) Flow 4.5 L/min Pressure Rating 0-6 bar (0-87 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/8" BSP Direction 3/2 Way Body Material Brass Sealing Material NBR (Nitrile Rubber) Flow 2.3 L/min Pressure Rating 0-5 bar (0-72 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/8" BSP Direction 3/2 Way Body Material Brass Sealing Material NBR (Nitrile Rubber) Flow 1.0 L/min Pressure Rating 0-15 bar (0-217 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Subplate Direction 3/2 Way Body Material Brass Sealing Material NBR (Nitrile Rubber) Flow 0.45 L/min Pressure Rating 0-20 bar (0-290 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Subplate Direction 3/2 Way Body Material Brass Sealing Material NBR (Nitrile Rubber) Flow 1.4 L/min Pressure Rating 0-15 bar (0-217 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Subplate Direction 3/2 Way Body Material Brass Sealing Material NBR (Nitrile Rubber) Flow 2.0 L/min Pressure Rating 0-10 bar (0-145 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Subplate Direction 3/2 Way Body Material Brass Sealing Material NBR (Nitrile Rubber) Flow 3.2 L/min Pressure Rating 0-6 bar (0-87 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Subplate Direction 3/2 Way Body Material Brass Sealing Material FKM (fluoroelastomer) Flow 3.2 L/min Pressure Rating 0-6 bar (0-87 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Subplate Direction 3/2 Way Body Material Brass Sealing Material FKM (fluoroelastomer) Flow 2.0 L/min Pressure Rating 0-10 bar (0-145 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Subplate Direction 3/2 Way Body Material Brass Sealing Material FKM (fluoroelastomer) Flow 1.4 L/min Pressure Rating 0-15 bar (0-217 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Subplate Direction 3/2 Way Body Material Brass Sealing Material FKM (fluoroelastomer) Flow 0.45 L/min Pressure Rating 0-20 bar (0-290 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Universal Pipe 1/8" BSP Direction 3/2 Way Body Material Brass Sealing Material FKM (Fluoroelastomer) Flow 0.8 L/min Pressure Rating 0-18 bar (0-261 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 3/2 Way Body Material Brass Sealing Material FKM (Fluoroelastomer) Flow 4.0 L/min Pressure Rating 0-5 bar (0-72 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 3/2 Way Body Material Brass Sealing Material FKM (Fluoroelastomer) Flow 3.2 L/min Pressure Rating 0-6 bar (0-87 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 3/2 Way Body Material Brass Sealing Material FKM (Fluoroelastomer) Flow 2.0 L/min Pressure Rating 0-10 bar (0-145 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Subplate Direction 3/2 Way Body Material Stainless Steel Sealing Material FKM (Fluoroelastomer) Flow 1.4 L/min Pressure Rating 0-15 bar (0 - 217 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size Flanged Direction 3/2 Way Body Material Brass Sealing Material RUBY Flow 1.4 L/min Pressure Rating 0-15 bar (0-217 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size Subplate Direction 3/2 Way Body Material Brass Sealing Material RUBY Flow 1.4 L/min Pressure Rating 0-15 bar (0-217 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1/8" BSP Direction 2/2 Way Body Material Plastic - PPS Sealing Material FKM (fluoroelastomer) Flow 1 L/min Pressure Rating 0-5 bar (0-72 psi) Certifications CSA, UL, CRN, NSF Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1/8" BSP Direction 2/2 Way Body Material Plastic - PPS Sealing Material FKM (fluoroelastomer) Flow 0.75 L/min Pressure Rating 0-15 bar (0-217 psi) Certifications CSA, UL, CRN, NSF Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.
