1/4" Solenoid Valves

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 1/4" NPT Direction 2/2 Way Body Material Brass Sealing Material FKM ( Fluoroelastomer) Flow 9.0 L/min Pressure Rating 0-2.5 bar (0 - 36 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Proportional Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material FKM (Fluoroelastomer) Flow 4 L/min Pressure Rating 0-5 bar (0 - 72 psi) Certifications CSA, UL, CRN, NSF Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material H-NBR (hydrogenated nitrile) Flow 4.0 L/min Pressure Rating 0-10 bar (0-145 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOW N LOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material H-NBR (hydrogenated nitrile) Flow 3.2 L/min Pressure Rating 0-14 bar (0-203 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOW N LOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material H-NBR (hydrogenated nitrile) Flow 2 L/min Pressure Rating 0-20 bar (0-290 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOW N LOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material H-NBR (hydrogenated nitrile) Flow 1.4 L/min Pressure Rating 0-25 bar (0-362 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOWNLOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material FKM (Fluoroelastomer) Flow 4.0 L/min Pressure Rating 0-10 bar (0-145 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOW N LOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material FKM (Fluoroelastomer) Flow 3.2 L/min Pressure Rating 0-14 bar (0-203 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOW N LOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material FKM (Fluoroelastomer) Flow 2 L/min Pressure Rating 0-20 bar (0-290 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOW N LOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material FKM (Fluoroelastomer) Flow 1.4 L/min Pressure Rating 0-25 bar (0-362 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOWNLOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material H-NBR (hydrogenated nitrile) Flow 4 L/min Pressure Rating 0-10 bar (0-145 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOWNLOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material H-NBR (hydrogenated nitrile) Flow 3.2 L/min Pressure Rating 0-14 bar (0-203 psi) Certifications CSA, UL, CRN, , ATEX Data Sheet DOWNLOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material H-NBR (hydrogenated nitrile) Flow 2.0 L/min Pressure Rating 0-22 bar (0-319 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOWNLOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material H-NBR (hydrogenated nitrile) Flow 1.4 L/min Pressure Rating 0-30 bar (0-435 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOWNLOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material FKM (Fluoroelastomer) Flow 4 L/min Pressure Rating 0-10 bar (0-145 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOWNLOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1/8" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material FKM (Fluoroelastomer) Flow 3.2 L/min Pressure Rating 0-14 Bar (0-203 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOWNLOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material FKM (Fluoroelastomer) Flow 2.0 L/min Pressure Rating 0-22 bar (0-319 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOWNLOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1/4" BSP Direction 2/2 Way Body Material Stainless Steel Sealing Material FKM (Fluoroelastomer) Flow 1.4 L/min Pressure Rating 0-30 bar (0-435 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOWNLOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Plastic - PPS Sealing Material RUBY + FKM (Fluoroelastomer) Flow 3.4 L/min Pressure Rating 0-16 bar (0 - 232 psi) Certifications CSA, UL, CRN, NSF Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Plastic - PPS Sealing Material RUBY + FKM (Fluoroelastomer) Flow 2.5 L/min Pressure Rating 0-16 bar (0 - 232 psi) Certifications CSA, UL, CRN, NSF Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Plastic - PPS Sealing Material RUBY + FKM (Fluoroelastomer) Flow 1.8 L/min Pressure Rating 0-16 bar (0 - 232 psi) Certifications CSA, UL, CRN, NSF Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Plastic - PPS Sealing Material RUBY + FKM (Fluoroelastomer) Flow 1.1 L/min Pressure Rating 0-16 bar (0 - 232 psi) Certifications CSA, UL, CRN, NSF Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Low Lead Brass Sealing Material FKM (Fluoroelastomer) Flow 0.45 L/min Pressure Rating 0-35 bar (0 - 507 psi) Certifications CSA, UL, CRN, NSF Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.
