Coils

Product Code BDA1X006LS Power 1.5W Voltage 6V Voltage Tolerance + 10% - 5% Housing Material PA - Black Polyamide Protection Degree IP 65 Insulation Class Class F (155°C) Ambient Temperature - 10°C + 60°C Certifications CE Data Sheet Download

Product Code BDA05009LS Power 5W Voltage 9V Voltage Tolerance + 10% - 5% Housing Material PA - Black Polyamide Protection Degree IP 65 Insulation Class Class F (155°C) Ambient Temperature - 10°C + 60°C Certifications CE Data Sheet Download

Product Code BDA05006LS Power 5W Voltage 6V Voltage Tolerance + 10% - 5% Housing Material PA - Black Polyamide Protection Degree IP65 Insulation Class Class F (155°C) Ambient Temperature - 10°C + 60°C Certifications CE Data Sheet Download

Product Code BDA2X006LS Power 2.5 W Voltage 6V Voltage Tolerance + 10% - 5% Housing Material PA - Black Polyamide Protection Degree IP 65 Insulation Class Class F (155°C) Ambient Temperature - 10°C + 60°C Certifications CE Data Sheet Download

Product Code BDA1X004LS Power 1.5 W Voltage 4.5V Voltage Tolerance + 10% - 5% Housing Material PA - Black Polyamide Protection Degree IP 65 Insulation Class Class F (155°C) Ambient Temperature - 10°C + 60°C Certifications CE Data Sheet Download

Product Code GDH14024CS Voltage 24 VDC Voltage Tolerance +10% - 5% ED 100% Housing Material PPS - Black polyphenylene sulfide Protection Degree IP65 Insulation Class Class N (200˚C) Ambient Temperature -20 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code GDA14012CS Voltage 12 VDC Voltage Tolerance +10% - 5% ED 100% Housing Material PA - Black polyamide Protection Degree IP65 Insulation Class Class F (155˚C) Ambient Temperature -20 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code LBV05110BU Voltage 110 VAC~ 60Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PET- Black Polyethylene Protection Degree IP65 Insulation Class Class H (180˚C) Ambient Temperature -20 + 40˚C Certifications CE, UL Download Data Sheet ⇲

Product Code LBV05024DY Voltage 24 VAC~ 50 - 60 Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PET- Black Polyethylene Protection Degree IP65 Insulation Class Class H (180˚C) Ambient Temperature -20 + 60˚C Certifications CE, UL, CSA, VDE Download Data Sheet ⇲

Product Code LBA05230AS Voltages Frequency 230 - 240 VAC~ 50 - 60Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PA - Black polyamide Protection Degree IP65 Insulation Class Class F (155˚C) Ambient Temperature -10 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code LBA05110AS Voltage 110 -120 VAC~ 50 - 60 Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PA - Black polyamide Protection Degree IP65 Insulation Class Class F (155˚C) Ambient Temperature -10 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code LBA05024AS Voltage 24 VAC~ 50Hz Voltage Tolerance +10% - 15% ED 100% Housing Material PA - Black polyamide Protection Degree IP65 Insulation Class Class F (155˚C) Ambient Temperature -10 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code UDV12230AY Voltage 230 - 240 VAC ~ 50 - 60 Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PET- Black Polyethylene Protection Degree IP65 Insulation Class Class H (180˚C) Ambient Temperature -20 + 60˚C Certifications CE, UL, CSA, VDE Download Data Sheet ⇲

Product Code UDA12230AS Voltage 230 VAC~ 50Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PA- Black Polyamide Protection Degree IP65 Insulation Class Class F (155˚C) Ambient Temperature -10 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code UDA12110DS Voltage 110 VAC~ 50/60 Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PA- Black Polyamide Protection Degree IP65 Insulation Class Class F (155˚C) Ambient Temperature -10 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code BDV08110BW Voltage 110 VAC~ 60Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PET- Black Polyethylene Protection Degree IP65 Insulation Class Class H (180˚C) Ambient Temperature -20 + 40˚C Certifications CE, UL, CSA Download Data Sheet ⇲

Product Code BDV08110CS Voltage 110 VDC Voltage Tolerance + 10% - 5% ED 100% Housing Material PET- Black Polyethylene Protection Degree IP65 Insulation Class Class H (180˚C) Ambient Temperature -40 + 60˚C Certifications CE Download Data Sheet ⇲

Product Code BDA08240AS Voltage 240 VAC ~ 50Hz Voltage Tolerance ED100% ED 100% Housing Material PA- Black Polyamide Protection Degree IP65 Insulation Class Class F (155˚C) Ambient Temperature -10 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code BDA08223DS Voltage 220/230 VAC ~ 50/60 Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PA - Black polyamide Protection Degree IP65 Insulation Class Class F (155˚C) Ambient Temperature -10 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code BDA08200DS Voltage 200 VAC ~ 50/60 Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PA- Black Polyamide Protection Degree IP65 Insulation Class Class F (150˚C) Ambient Temperature -10 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code BDA08115BS Voltage 115 VAC ~ 60 Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PA- Black Polyamide Protection Degree IP65 Insulation Class Class F (155˚C) Ambient Temperature -10 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code BDA08110DS Voltages Frequency 110 VAC~ 50/60 Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PA- Black Polyamide Protection Degree IP65 Insulation Class Class F (155˚C) Ambient Temperature -10 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code BDA08024DS Voltage 24 VAC ~ 50/ 60Hz Voltage Tolerance + 10% - 15% ED 100% Housing Material PA- Black Polyamide Protection Degree IP65 Insulation Class Class F (155˚C) Ambient Temperature -10 + 40˚C Certifications CE Download Data Sheet ⇲

Product Code BDA08024CS Voltage 24 VDC Voltage Tolerance + 10% - 5% ED ED100% Housing Material PA- Black Polyamide Protection Degree IP65 Insulation Class Class F (155˚C) Ambient Temperature -10 + 40˚C Certifications CE Download Data Sheet ⇲
