1/4" Solenoid Valves

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" NPT Direction 2/2 Way Body Material Brass Sealing Material FKM (Fluoroelastomer) Flow 1.4 L/min Pressure Rating 0-30 bar (0 - 435 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material EPDM (ethylene-propylene) Flow 9.0 L/min Pressure Rating 0-10 bar (0 - 145 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material EPDM (ethylene-propylene) Flow 6.5 L/min Pressure Rating 0-12 Bar (0 - 174 PSI) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material EPDM (ethylene-propylene) Flow 4.0 L/min Pressure Rating 0-25 bar (0 - 362 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material EPDM (ethylene-propylene) Flow 3.2 L/min Pressure Rating 0-30 Bar (0 - 435 PSI) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material EPDM (ethylene-propylene) Flow 2.0 L/min Pressure Rating 0-35 Bar (0 - 507 PSI) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material FKM (Fluoroelastomer) Flow 4.0 L/min Pressure Rating 0-25 bar (0 - 362 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material NBR (Nitrile Rubber) Flow 4.0 L/min Pressure Rating 0-25 bar (0 - 362 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Stainless Steel - SS316 Sealing Material FKM (Fluoroelastomer) Flow 9.0 L/min Pressure Rating 0-10 bar (0-145 psi) Certifications CSA, UL, CRN, NSF Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Stainless Steel - SS316 Sealing Material FKM (Fluoroelastomer) Flow 5.0 L/min Pressure Rating 0-15 Bar (0-217 PSI) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Stainless Steel - SS316 Sealing Material FKM (Fluoroelastomer) Flow 4.0 L/min Pressure Rating 0-25 Bar (0-362 PSI) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Stainless Steel - SS316 Sealing Material FKM (Fluoroelastomer) Flow 3.2 L/min Pressure Rating 0-30 Bar (0-435 PSI) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1/4" NPT Direction 3/2 Way Body Material Anodized Aluminum Sealing Material FPM (Fluoroelastomer) Flow (CV) 0.74 gpm Pressure Rating 0-9 bar (0-130 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe Size 1/4" NPT Direction 2/2 Way Body Material Brass Sealing Material FPM (Fluoroelastomer) Flow (CV) 0.173 gpm Pressure Rating 0-14 bar (0-203 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type Explosion Proof- ATEX Ex d Solenoid Valve Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Stainless Steel - SS316 Sealing Material FKM (Fluoroelastomer) Flow 3.2 L/min Pressure Rating 0-14 bar (0-203 psi) Certifications CSA, UL, CRN, ATEX Data Sheet DOWNLOAD Instruction Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 1/4" NPT Direction 2/2 Way Body Material Brass Sealing Material FKM ( Fluoroelastomer) Flow 3.2 L/min Pressure Rating 0-14 Bar (0 - 203 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Plastic - PPS Sealing Material FKM (Fluoroelastomer) Flow 3.4 L/min Pressure Rating 0-16 bar (0 - 232 psi) Certifications CSA, UL, CRN, NSF Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material FKM ( Fluoroelastomer) Flow 9.0 L/min Pressure Rating 0-2.5 bar (0 - 36 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material FKM ( Fluoroelastomer) Flow 6.5 L/min Pressure Rating 0-4 bar (0 - 58 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material FKM (Fluoroelastomer) Flow 4.0 L/min Pressure Rating 0-10 bar (0 - 145 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material FKM ( Fluoroelastomer) Flow 3.2 L/min Pressure Rating 0-14 bar (0 - 203 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material FKM ( Fluoroelastomer) Flow 2.0 L/min Pressure Rating 0-20 bar (0 - 290 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Open Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material FKM (Fluoroelastomer) Flow 1.4 L/min Pressure Rating 0-25 bar (0 - 362 psi) Certifications CSA, UL, CRN Data Sheet ⇲ DOWNLOAD ⚠ 3D Drawings are available upon request.

Valve Function Direct Acting Valve Type General Purpose Solenoid Valve Fitting Type Connector Actuation Electric (Solenoid) Valve Starting Position Normally Closed Pipe 1/4" BSP Direction 2/2 Way Body Material Brass Sealing Material EPDM (ethylene-propylene) Flow 6.5 L/min Pressure Rating 0 - 5 bar (0 - 72 psi) Certifications CSA, UL, CRN Data Sheet DOWNLOAD ⚠ 3D Drawings are available upon request.
